Terex Manlift Specifications
Based in Westport, Connecticut, Terex specializes in making construction machinery. They make machinery like boom lifts, aerial lifts and manlifts. These machines are designed to facilitate access to difficult to reach places, buildings and roofs, large equipment, among other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration refers to a power-driven endless belt. This belt moves just in one direction and includes handholds or platforms or steps that are attached to the unit in order to transport personnel from every floor.
TB85
Terex's TB85 man lift provides a max working height at 91 feet. The platform's max height reaches 85 feet, while the maximum width of the model is 8.5 feet. The TB85 has dimensions measuring 9 feet, 1-inch high and 9 inches wide by 36 feet. This particular model provides a reach of 70 feet. The TB85 has a boom angle below horizontal measures at -14 degrees and above horizontal reaching 75 degrees.
Terex TB100
The Terex TB100 man lift's maximum height is 106 feet and the maximum height of the platform is 100 feet. The TB100 when stowed away, is roughly 8.5 feet wide by 9 feet high by 8 feet. The maximum width of the unit is 8 feet, 1 1/2 inches. The boom angle above horizontal is 75 degrees and below horizontal is 14 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The TB110 has a maximum platform height of 100 feet and the unit's maximum working height overall reaches 116 feet. When stowed, this model is 9 feet, 4 inches high x 8 feet wide. The TB110 provides a horizontal reach of 67 feet and a maximum width of 8 feet. This model has a boom angle of 75 degrees above horizontal plus 10 degrees articulating. Below horizontal it is -14 degrees and it measures -105 degrees articulating.
